Diamond Rope Saw (Multi Wire)
QIDELI
QDL-wire saw-004
Unleash the Power of QIDELI Diamond Rope Saw!
Diamond wire is now widely used in factories to process stone blocks into slabs. Multi wire machines using small diameter diamond wires can cut all types of stones, from soft stone and marbles to granite and quarzite. Offering higher material yield, faster cutting, and lower power consumption.
All diamond wires are developed based on the characteristics of the machines and main materials to be cut to provide the best solution for the customers.
● High cutting efficiency.
● Flat and smoother slabs.
● Low power consumption and less material waste.
● Low noise and environmentally friendly
| Model | Diameter(mm) | Beads(m) | Fixing | Note |
| QDL-DWS-014 | Φ8.5 | 37 | Plastic | All wires are developed based on the characteristics of stone samples and information provided by customers for highest cutting efficiency. |
| QDL-DWS-015 | Φ7.3 | 37 | ||
| QDL-DWS-016 | Φ6.3 | 37 | ||
| QDL-DWS-017 | Φ5.3 | 37 |
| Hardness of stone | Wire speed (m/s) | Cutting speed (m²/h) | Production (m²/m) | |
| Soft | 30-33 | 1.2-1.5 | 10-15 | |
| Medium | 28-32 | 0.6-1.2 | 8-12 | |
| Hard | 26-32 | 0.4-0.6 | 5-8 | |
| Quarzite | 26-32 | 0.4-0.6 | 5-8 | |
 |  |
 |  |
|
 |
| Why Choose QIDELI? |
| Founded in 1990, QIDELI has established itself as a leader in the production, research, and development of drilling tools for mining, well drilling, tunneling, and more. Our export arm, Putian Qideli Engineering Equipment Co., Ltd., entered the international market in 2017 and has since achieved remarkable growth, driven by our commitment to quality, innovation, and customer satisfaction. |
| At QIDELI, we prioritize customer success and satisfaction above all else. Our dedication to excellence, combined with decades of expertise and cutting-edge technology, ensures that choosing QIDELI means choosing reliability, efficiency, and performance excellence for all your cutting needs. |
